Chapter 17: Metaprogramming, Big Picture

Tony ElHabr

R4DS Reading Group

1 / 61

What is metaprogramming?

2 / 61

What is metaprogramming?

3 / 61

What is metaprogramming?

4 / 61

What is metaprogramming?

5 / 61

What is metaprogramming?

6 / 61

What is metaprogramming?

7 / 61

What is metaprogramming?

Writing programs (or code) that can manipulate other programs (or code).

8 / 61

What is metaprogramming?

Writing programs (or code) that can manipulate other programs (or code).

Does metaprogamming == Non Standard Evaluation (NSE)?

[Metaprogramming] is the idea that code is data that can be inspected and modified programmatically... Closely related to metaprogramming is non-standard evaluation, NSE for short. This term, which is commonly used to describe the behaviour of R functions, is problematic.. NSE is actually a property of the argument (or arguments) of a function, so talking about NSE functions is a little sloppy.

9 / 61

Big Ideas

10 / 61

Big Ideas

11 / 61

Big Ideas

12 / 61

Big Ideas

13 / 61

Big Ideas

14 / 61

1. R code is a tree

16 / 61

1. R code is a tree

17 / 61

1. R code is a tree

But what does that mean???

18 / 61

1. R code is a tree

But what does that mean???

"R code can be described as expressions, which can be drawn as trees."

An expression is anything that has a value. The simplest expressions are literal values like the number 1, the string "stuff", and the Boolean TRUE. A variable like least is also an expression: its value is whatever the variable currently refers to. Complex expressions are built out of simpler expressions: 1 + 2 is an expression that uses + to combine 1 and 2, while the expression c(10, 20, 30) uses the function c to create a vector out of the values 10, 20, 30. Expressions are often drawn as trees.

19 / 61

1. R code is a tree

But what does that mean???

"R code can be described as expressions, which can be drawn as trees."

An expression is anything that has a value. The simplest expressions are literal values like the number 1, the string "stuff", and the Boolean TRUE. A variable like least is also an expression: its value is whatever the variable currently refers to. Complex expressions are built out of simpler expressions: 1 + 2 is an expression that uses + to combine 1 and 2, while the expression c(10, 20, 30) uses the function c to create a vector out of the values 10, 20, 30. Expressions are often drawn as trees.

lobstr::ast(f(x, 'y', 1))
## o-f
## +-x
## +-"y"
## \-1
20 / 61

1. R code is a tree

But what does that mean???

"R code can be described as expressions, which can be drawn as trees."

An expression is anything that has a value. The simplest expressions are literal values like the number 1, the string "stuff", and the Boolean TRUE. A variable like least is also an expression: its value is whatever the variable currently refers to. Complex expressions are built out of simpler expressions: 1 + 2 is an expression that uses + to combine 1 and 2, while the expression c(10, 20, 30) uses the function c to create a vector out of the values 10, 20, 30. Expressions are often drawn as trees.

lobstr::ast(f(x, 'y', 1))
## o-f
## +-x
## +-"y"
## \-1

Colours will be shown when you call ast(), but do not appear in the book for complicated technical reasons.

21 / 61

1. R code is a tree

But what does that mean???

"R code can be described as expressions, which can be drawn as trees."

An expression is anything that has a value. The simplest expressions are literal values like the number 1, the string "stuff", and the Boolean TRUE. A variable like least is also an expression: its value is whatever the variable currently refers to. Complex expressions are built out of simpler expressions: 1 + 2 is an expression that uses + to combine 1 and 2, while the expression c(10, 20, 30) uses the function c to create a vector out of the values 10, 20, 30. Expressions are often drawn as trees.

lobstr::ast(f(x, 'y', 1))
## o-f
## +-x
## +-"y"
## \-1

Colours will be shown when you call ast(), but do not appear in the book for complicated technical reasons.

22 / 61

1. R code is a tree

But what does that mean???

"R code can be described as expressions, which can be drawn as trees."

An expression is anything that has a value. The simplest expressions are literal values like the number 1, the string "stuff", and the Boolean TRUE. A variable like least is also an expression: its value is whatever the variable currently refers to. Complex expressions are built out of simpler expressions: 1 + 2 is an expression that uses + to combine 1 and 2, while the expression c(10, 20, 30) uses the function c to create a vector out of the values 10, 20, 30. Expressions are often drawn as trees.

lobstr::ast(f(x, 'y', 1))
## o-f
## +-x
## +-"y"
## \-1

Colours will be shown when you call ast(), but do not appear in the book for complicated technical reasons.

23 / 61

1. R code is a tree

Everything is a tree!

24 / 61

1. R code is a tree

Everything is a tree!

Assignment and infix operator (*)

x <- 1
lobstr::ast(y <- 2 * x)
## o-`<-`
## +-y
## \-o-`*`
## +-2
## \-x

Control flow statements

lobstr::ast(if(x > 1) y else x)
## o-`if`
## +-o-`>`
## | +-x
## | \-1
## +-y
## \-x
25 / 61

1. R code is a tree

Everything is a tree!

Assignment and infix operator (*)

x <- 1
lobstr::ast(y <- 2 * x)
## o-`<-`
## +-y
## \-o-`*`
## +-2
## \-x

Control flow statements

lobstr::ast(if(x > 1) y else x)
## o-`if`
## +-o-`>`
## | +-x
## | \-1
## +-y
## \-x

Functions

lobstr::ast(function(x, y) x + y)
## o-`function`
## +-o-x = ``
## | \-y = ``
## +-o-`+`
## | +-x
## | \-y
## \-<inline srcref>

ASTs

lobstr::ast(lobstr::ast(x + y))
## o-o-`::`
## | +-lobstr
## | \-ast
## \-o-`+`
## +-x
## \-y
26 / 61

2. Capture trees by quoting

27 / 61

2. Capture trees by quoting

ex1 <- rlang::expr(x + y)
ex1
## x + y
28 / 61

2. Capture trees by quoting

ex1 <- rlang::expr(x + y)
ex1
## x + y
x <- 1
y <- 2
eval(ex1)
## [1] 3
lobstr::ast(1 + 2)
## o-`+`
## +-1
## \-2
29 / 61

2. Capture trees by quoting

30 / 61

2. Capture trees by quoting

rlang::expr vs. rlang::enexpr

31 / 61

2. Capture trees by quoting

rlang::expr vs. rlang::enexpr

rlang::expr quotes your expression

f1 <- function(z) expr(z)
f1(a + b)
## z
32 / 61

2. Capture trees by quoting

rlang::expr vs. rlang::enexpr

rlang::expr quotes your expression

f1 <- function(z) expr(z)
f1(a + b)
## z

enexpr quotes user's expression

f2 <- function(z) enexpr(z)
f2(a + b)
## a + b
33 / 61

2. Capture trees by quoting

rlang::expr vs. rlang::enexpr

rlang::expr quotes your expression

f1 <- function(z) expr(z)
f1(a + b)
## z

enexpr quotes user's expression

f2 <- function(z) enexpr(z)
f2(a + b)
## a + b

en = "enriched"

34 / 61

2. Capture trees by quoting

35 / 61

2. Capture trees by quoting

mean(x + y)

library(ggplot2)

# ggplot(mtcars, aes(disp, mpg)) + geom_point()

mtcars$disp

z <- x + 1

data.frame(z = 3)

Blue: Evaluated using usual R rules

Red: Quoted and evaluated with special rules

36 / 61

3. Build trees by unquoting

37 / 61

3. Build trees by unquoting

lobstr::ast(eval(!!ex1))
## o-eval
## \-o-`+`
## +-x
## \-y
38 / 61

3. Build trees by unquoting

lobstr::ast(eval(!!ex1))
## o-eval
## \-o-`+`
## +-x
## \-y
ex2 <- rlang::expr(x / !!ex1)
ex2
## x/(x + y)
39 / 61

3. Build trees by unquoting

lobstr::ast(eval(!!ex1))
## o-eval
## \-o-`+`
## +-x
## \-y
ex2 <- rlang::expr(x / !!ex1)
ex2
## x/(x + y)
eval(ex2)
## [1] 0.3333333
40 / 61

3. Build trees by unquoting

lobstr::ast(eval(!!ex1))
## o-eval
## \-o-`+`
## +-x
## \-y
ex2 <- rlang::expr(x / !!ex1)
ex2
## x/(x + y)
eval(ex2)
## [1] 0.3333333
lobstr::ast(eval(!!ex2))
## o-eval
## \-o-`/`
## +-x
## \-o-`+`
## +-x
## \-y
41 / 61

3. Build trees by unquoting

Understanding how to build code trees == success in online arguments.

42 / 61

3. Build trees by unquoting

Understanding how to build code trees == success in online arguments.

43 / 61

3. Build trees by unquoting

Understanding how to build code trees == success in online arguments.

44 / 61

3. Build trees by unquoting

Understanding how to build code trees == success in online arguments.

x <- 8 / 2 * (2 + 2)
lobstr::ast(x <- 8 / 2 * (2 + 2))
## o-`<-`
## +-x
## \-o-`*`
## +-o-`/`
## | +-8
## | \-2
## \-o-`(`
## \-o-`+`
## +-2
## \-2
x
## [1] 16
45 / 61

4. Capture trees AND
environments

46 / 61

4. Capture trees AND
environments

quosure == closure + quote

47 / 61

4. Capture trees AND
environments

quosure == closure + quote

Quosures aremportant for disambiguating the context in which expressions are evaluated (e.g. a column in a data frame or a variable in the parent environment).

48 / 61

4. Capture trees AND
environments

Result is tibble(x = 0, y = 1).

update <- function(df, col) {
  n <- 1
  col <- rlang::enexpr(col)
  res <- dplyr::mutate(df, y = !!col)
  res
}

df <- tibble::tibble(x = 0)
n <- 2
update(df, x + n)

49 / 61

4. Capture trees AND
environments

50 / 61

4. Capture trees AND
environments

Result is tibble(x = 0, y = 2).

update <- function(df, col) {
  n <- 1
  col <- rlang::enquo(col)
  res <- dplyr::mutate(df, y = !!col)
  res
}

df <- tibble::tibble(x = 0)
n <- 2
update(df, x + n)

51 / 61

4. Capture trees AND
environments

52 / 61

The Power of Metaprogramming

53 / 61

The Power of Metaprogramming

Metaprogramming is awesome. R is great because of how much control it allows user to have.

54 / 61

The Power of Metaprogramming

Metaprogramming is awesome. R is great because of how much control it allows user to have.

55 / 61

What's next

  • Chapter 18: More about R code as a tree

  • Chapter 19: More about evaluating (quoting) unevaluated code

  • Chapter 20: More about evaluating (unquoting) captured code

56 / 61

Aside about trees

57 / 61

Aside about trees

Understanding how "code is a tree" would have helped me with my final project in my Intro to Programming class.

58 / 61

Aside about trees

Understanding how "code is a tree" would have helped me with my final project in my Intro to Programming class.

Please note that whether you choose to explicitly build a parse tree or not, you will almost certainly have to write your parsing and executing function(s) using recursion. Fortunately, the recursion required to do this is super easy (whether you build a parse tree or not, the recursion is very natural).


Implementing a Parse Tree is optional for Phase A. In Phase B, we will almost certainly mandate that you have a Parse Tree, and for Phase B, the parse trees are decidedly more complicated, since you will have both Expressions to represent and Statements to represent.

59 / 61

Aside about trees

60 / 61

Aside about trees


61 / 61
