class: center, middle, inverse, title-slide # Advanced R ## Chapter 4: Subsetting ### Alan Kinene
@alankinene
&
Shel Kariuki
@Shel_Kariuki
### 2020/08/25 --- class: middle # Outline - Section 4.1: Introduction - Section 4.2: Selecting multiple elements - Section 4.3: Selecting a single element -- - Section 4.4: Subsetting and assignment - Section 4.5: Applications (Using subsetting to solve problems) --- class: middle # Introduction - Interrelated concepts to internalise: + There are 3 subsetting operators: `[[`, `[`, and `$` + Subsetting operators interact differently with various vector types (e.g. atomic vectors, lists, factors, matrices, and data frames) + Subsetting and assignment can be combined ("subsassignment") > Subsetting complements structure, or `str()`, which shows you *all* the pieces of an object, but subsetting lets you pull out only the pieces you are interested in. > Often useful to use RStudio Viewer, with `View(my_object)` to know which pieces you want to subset --- class: center, middle, inverse # 4.2: Selecting multiple elements --- class: middle # Subsetting atomic vectors > Use `[` to select any number of elements from a vector. -- Assume we have a simple vector: `x <- c(2.1, 4.2, 3.3, 5.4)` + Positive integers return elements at the specified positions: ```r x[c(3, 1)] ``` ``` ## [1] 3.3 2.1 ``` + Negative integers exclude elements at the specified positions: ```r x[-c(3, 1)] ``` ``` ## [1] 4.2 5.4 ``` --- class: middle # Subsetting atomic vectors + Logical vectors select elements where the corresponding logical value is `TRUE` ```r x[c(TRUE, TRUE, FALSE, FALSE)] ``` ``` ## [1] 2.1 4.2 ``` ```r x[x > 3] ``` ``` ## [1] 4.2 3.3 5.4 ``` > `x[c(TRUE, FALSE)]` is equivalent to `x[c(TRUE, FALSE, TRUE, FALSE)]` + Nothing returns the original vector. ```r x[] ``` ``` ## [1] 2.1 4.2 3.3 5.4 ``` --- class: middle + Zero returns a zero-length vector. ```r x[0] ``` ``` ## numeric(0) ``` + Named vector ```r (y <- setNames(x, letters[1:4])) ``` ``` ## a b c d ## 2.1 4.2 3.3 5.4 ``` ```r y[c("d", "c", "a")] ``` ``` ## d c a ## 5.4 3.3 2.1 ``` --- class: middle # Subsetting lists * Subsetting a list works in the same way as subsetting an atomic vector. * Using `[` always returns a list * `[[` and `$`, as described in *Section 4.3*, let you pull out elements of a list. --- class: middle # Subsetting matrices and arrays > The most common way of subsetting matrices (2D) and arrays (>2D) is a simple generalisation of 1D subsetting #### Subset with multiple vectors. ```r a <- matrix(1:9, nrow = 3) colnames(a) <- c("A", "B", "C") ``` .pull-left[ ```r a[1:2, ] ``` ``` ## A B C ## [1,] 1 4 7 ## [2,] 2 5 8 ``` ] .pull-right[ ```r a[c(TRUE, FALSE, TRUE), c("B", "A")] ``` ``` ## B A ## [1,] 4 1 ## [2,] 6 3 ``` ] --- # Subsetting matrices and arrays Consider the matrix below: ```r (vals = matrix(1:25, ncol = 5, byrow = TRUE)) ``` ``` ## [,1] [,2] [,3] [,4] [,5] ## [1,] 1 2 3 4 5 ## [2,] 6 7 8 9 10 ## [3,] 11 12 13 14 15 ## [4,] 16 17 18 19 20 ## [5,] 21 22 23 24 25 ``` .pull-left[ ####*Subset with a single vector* ```r vals[c(4, 15)] ``` ``` ## [1] 16 23 ``` ] .pull-right[ #### *Subset with a matrix* ```r select <- matrix(ncol = 2, byrow = TRUE, c( 1, 1, 3, 1, 2, 4 )) vals[select] ``` ``` ## [1] 1 11 9 ``` ] --- class: middle # Subsetting data frames and tibbles + Data frames have the characteristics of both lists and matrices. + When subsetting with a single index, they behave like lists and index the columns, so `df[1:2]` selects the first two columns. + When subsetting with two indices, they behave like matrices, so `df[1:3, ]` selects the first three rows (and all the columns > Given `df <- data.frame(x = 1:3, y = 3:1, z = letters[1:3])` what is the output for:<br> `df[df$x == 2, ]`,<br> `df[c("x", "z")]`, <br> `df[, c("x", "z")]`,<br> `str(df["x"])`, and <br>`str(df[, "x"])`? --- # Preserving dimensionality > By default, subsetting a matrix or data frame with a single number, **a single name**, or **a logical vector** containing a single `TRUE`, will simplify the returned output, i.e. it will return an object with lower dimensionality. > To preserve the original dimensionality, you must use `drop = FALSE` .pull-left[ ####*For matrices and arrays, any <br> dimensions with length 1 will <br>be dropped:* ```r a <- matrix(1:4, nrow = 2) str(a[1, ]) ``` ``` ## int [1:2] 1 3 ``` ```r str(a[1, , drop = FALSE]) ``` ``` ## int [1, 1:2] 1 3 ``` ] .pull-right[ ####*Data frames with a single column <br> will return just that column* ```r df <- data.frame(a = 1:2, b = 1:2) str(df[, "a"]) ``` ``` ## int [1:2] 1 2 ``` ```r str(df[, "a", drop = FALSE]) ``` ``` ## 'data.frame': 2 obs. of 1 variable: ## $ a: int 1 2 ``` ] --- class: middle # 4.3: Selecting a single element > There are two other subsetting operators: `[[` and `$`.<br> `[[` is used for extracting single items, while `x$y` is a useful shorthand for `x[["y"]]` --- class: middle # Use of `[[` + Primary use case for `[[` is when working with lists, as you get a list back. > If list x is a train carrying objects, then `x[[5]]` is the object in car `5`; `x[4:6]` is a train of cars `4-6`.— @RLangTip ```r x <- list(1:3, "a", 4:6) ``` --- # Use of `[[` <center> <img src="img/train.png" width="60%" /> <img src="img/train-single.png" width="60%" /> </center> --- # Use of `[[` <center> <img src="img/train.png" width="60%" /> <img src="img/train-many.png" width="60%" /> </center> + If you use a vector with `[[`, it will subset recursively, i.e. `x[[c(1, 2)]]` is equivalent to `x[[1]][[2]]`. --- class: middle # Use of `$` + `$` is a shorthand operator: `x$y` is roughly equivalent to `x[["y"]]`. + Often used to access variables in a data frame, as in mtcars$cyl or diamonds$carat. + One common mistake with `$` is to use it when you have the name of a column stored in a variable: > If `var <- "cyl"`, `mtcars$var` doesn't work because it is translated to `mtcars[["var"]]`. Instead use `mtcars[[var]]` --- # Use of `$` + The one important difference between `$` and `[[` is that `$` does (left-to-right) partial matching. ```r x <- list(abc = 1) x$a ``` ``` ## [1] 1 ``` ```r x[["a"]] ``` ``` ## NULL ``` + You can avoid this behaviour: ```r options(warnPartialMatchDollar = TRUE) x$a ``` ``` ## [1] 1 ``` > **Remember:** For data frames, you can also avoid this problem by using tibbles, which never do partial matching. --- class: middle # Using @ and slot() + Two additional subsetting operators, which are needed for S4 objects: 1. `@` (equivalent to `$`) 2. `slot()` (equivalent to `[[`). > `@` is more restrictive than `$` in that it will return an error if the slot does not exist. --- class: center background-image:url("img/exercises.jpg") # Exercises <br> # . <br> # . <br> # . --- # 4.4: Subsetting and assignment Subassignment: Combining subsetting operators with assignments to modify selected values in an input vector. The basic form is `x[i] <- value` Ensure that: - `length(value)` == `length(x[i])` ```r # wafanyikazi$new_var <- 1:10000 # Error in `$<-.data.frame`(`*tmp*`, new_var, value = 1:10000) : #replacement has 10000 rows, data has 500 ``` - `i` is unique --- To remove a component, use `x[[i]] <- NULL` ```r departments <- list("data", "operations", "finance") departments ``` ``` ## [[1]] ## [1] "data" ## ## [[2]] ## [1] "operations" ## ## [[3]] ## [1] "finance" ``` ```r departments[[3]] <- NULL departments ``` ``` ## [[1]] ## [1] "data" ## ## [[2]] ## [1] "operations" ``` To add a literal NULL, use `x[i] <- list(NULL)` ```r departments[3] <- list(NULL) departments ``` ``` ## [[1]] ## [1] "data" ## ## [[2]] ## [1] "operations" ## ## [[3]] ## NULL ``` --- # 4.5: Applications (Using subsetting to solve problems) - Lookup tables (character subsetting) -- - Matching and merging by hand (integer subsetting) -- - Random samples and bootstraps (integer subsetting) -- - Ordering (integer subsetting) -- - Expanding aggregated counts (integer subsetting) -- - Removing columns from data frames (character ) -- - Selecting rows based on a condition (logical subsetting) -- - Boolean algebra versus sets (logical and integer ) --- ##4.5.1 Lookup tables (character subsetting) Character matching ```r x <- c("m", "f", "u", "f", "f", "m", "m") lookup <- c(m = "Male", f = "Female", u = NA) lookup[x] ## Is this the same as saying look for x in the vector lookup? Is it also the same as using an ifelse function? ``` ``` ## m f u f f m m ## "Male" "Female" NA "Female" "Female" "Male" "Male" ``` We can exclude names in the results using: ```r unname(lookup[x]) ``` ``` ## [1] "Male" "Female" NA "Female" "Female" "Male" "Male" ``` --- ##4.5.2 Matching and merging by hand (integer subsetting) ```r grades <- c(1, 2, 2, 3, 1) info <- data.frame( grade = 3:1, desc = c("Excellent", "Good", "Poor"), fail = c(F, F, T) ) head(info) ``` ``` ## grade desc fail ## 1 3 Excellent FALSE ## 2 2 Good FALSE ## 3 1 Poor TRUE ``` Assuming we want to duplicate the info table so that we have a row for each value in grades. `match(needles, haystack)` // look for (needles, haystack) --- What is the position of the needles [grades elements : (1,2,2,3,1)] in the haystack [info$grade: (3,2,1)] ```r id <- match(grades, info$grade) id ``` ``` ## [1] 3 2 2 1 3 ``` ```r info[id, ] ``` ``` ## grade desc fail ## 3 1 Poor TRUE ## 2 2 Good FALSE ## 2.1 2 Good FALSE ## 1 3 Excellent FALSE ## 3.1 1 Poor TRUE ``` When matching on multiple columns, you will need to first collapse them into a single column (with e.g `interaction()`). ```r ## insert intersection code here ``` But dplyr{} `*_join()` functions would be your best friends at this point --- ##4.5.3 Random samples and bootstraps (integer subsetting) Using integer indices to randomly sample or bootstrap a vector or data frame. Use `sample(n)` to generate a random permutation of `1:n`, and then use the results to subset the values Simulate a dataframe ```r df = data.frame(names = c("John", "Teresa", "Shel", "Christine", "Brenda"), gender = c("M", "F", "F", "F", "F"), rshp = c("Father", "Mother", "Self", "Sister", "Sister")) df ``` ``` ## names gender rshp ## 1 John M Father ## 2 Teresa F Mother ## 3 Shel F Self ## 4 Christine F Sister ## 5 Brenda F Sister ``` --- Reorder the dataframe randomly ```r df[sample(nrow(df)), ] ``` ``` ## names gender rshp ## 1 John M Father ## 5 Brenda F Sister ## 4 Christine F Sister ## 3 Shel F Self ## 2 Teresa F Mother ``` Select two random rows ```r df[sample(nrow(df), 2), ] ``` ``` ## names gender rshp ## 5 Brenda F Sister ## 3 Shel F Self ``` Select 7 bootstrap replicates ```r df[sample(nrow(df), 7, replace = T), ] ``` ``` ## names gender rshp ## 5 Brenda F Sister ## 3 Shel F Self ## 5.1 Brenda F Sister ## 3.1 Shel F Self ## 3.2 Shel F Self ## 1 John M Father ## 1.1 John M Father ``` --- ##4.5.4 Ordering (integer subsetting) `order()` takes a vector as its input and returns an integer vector describing how to order the subsetted vector ```r fam <- c("John", "Teresa", "Shel", "Christine", "Brenda") order(fam) ## orders alphabetically (in ascending order by default) ``` ``` ## [1] 5 4 1 3 2 ``` ```r fam[order(fam)] ``` ``` ## [1] "Brenda" "Christine" "John" "Shel" "Teresa" ``` ```r ## We can also order the vector in ascending order fam[order(fam, decreasing = T)] ``` ``` ## [1] "Teresa" "Shel" "John" "Christine" "Brenda" ``` _NB: By default, any missing values will be put at the end of the vector; however, you can remove them with `na.last = NA` or put them at the front with `na.last = FALSE`._ ```r # us <- c("Me", "You", NA) # us[order(us)] # us[order(us, na.last = FALSE)] ``` --- Using `order()` to order values in a variable, or variables themselves, in a dataframe ```r # Randomly reorder df df2 <- df[sample(nrow(df)), 3:1] df2 ``` ``` ## rshp gender names ## 4 Sister F Christine ## 2 Mother F Teresa ## 3 Self F Shel ## 1 Father M John ## 5 Sister F Brenda ``` ```r # Order by one variable df[order(df$gender), ] ``` ``` ## names gender rshp ## 2 Teresa F Mother ## 3 Shel F Self ## 4 Christine F Sister ## 5 Brenda F Sister ## 1 John M Father ``` --- ```r # Order the variables themselves df[, order(names(df))] ``` ``` ## gender names rshp ## 1 M John Father ## 2 F Teresa Mother ## 3 F Shel Self ## 4 F Christine Sister ## 5 F Brenda Sister ``` _You can sort vectors directly with `sort()`, or similarly `dplyr::arrange()`, to sort a data frame._ --- ##4.5.5 Expanding aggregated counts (integer subsetting) ```r df <- data.frame(x = c(2, 4, 1), y = c(9, 11, 6), n = c(3, 5, 1)) df ``` ``` ## x y n ## 1 2 9 3 ## 2 4 11 5 ## 3 1 6 1 ``` ```r rep(1:nrow(df), df$n) ``` ``` ## [1] 1 1 1 2 2 2 2 2 3 ``` ```r df[rep(1:nrow(df), df$n), ] ``` ``` ## x y n ## 1 2 9 3 ## 1.1 2 9 3 ## 1.2 2 9 3 ## 2 4 11 5 ## 2.1 4 11 5 ## 2.2 4 11 5 ## 2.3 4 11 5 ## 2.4 4 11 5 ## 3 1 6 1 ``` --- ##4.5.6 Removing columns from data frames (character ) Method 1: Set individual columns to NULL ```r df = data.frame(names = c("John", "Teresa", "Shel", "Christine", "Brenda"), gender = c("M", "F", "F", "F", "F"), rshp = c("Father", "Mother", "Self", "Sister", "Sister")) df ``` ``` ## names gender rshp ## 1 John M Father ## 2 Teresa F Mother ## 3 Shel F Self ## 4 Christine F Sister ## 5 Brenda F Sister ``` ```r ## create a copy of the dataframe df2 <- df ## drop a column df2$gender <- NULL df2 ``` ``` ## names rshp ## 1 John Father ## 2 Teresa Mother ## 3 Shel Self ## 4 Christine Sister ## 5 Brenda Sister ``` --- Method 2: Subset to return only the columns you want ```r df[c("names", "rshp")] ``` ``` ## names rshp ## 1 John Father ## 2 Teresa Mother ## 3 Shel Self ## 4 Christine Sister ## 5 Brenda Sister ``` Method 3: Use set operations to work out which columns to keep. This is useful when you only know the columns that you don't want. ```r to_keep <- setdiff(names(df), "gender") to_keep ``` ``` ## [1] "names" "rshp" ``` ```r df[to_keep] ``` ``` ## names rshp ## 1 John Father ## 2 Teresa Mother ## 3 Shel Self ## 4 Christine Sister ## 5 Brenda Sister ``` --- ##4.5.7 Selecting rows based on a condition (logical subsetting) ```r library(rChambua) head(wafanyikazi, n=3) ``` ``` ## Sid Gender Age Department Role Income Marital_Status County ## 1 10715 Male 31 Finance Mid 5991 Single Kisumu ## 2 17041 Male 48 Research Analyst Junior 3387 Divorced Wajir ## 3 16232 Male 35 Operations Junior 3170 Married Mombasa ## Leave_Days Promotion ## 1 11 No ## 2 8 Yes ## 3 0 No ``` Select all juniors ```r df1 <- wafanyikazi[wafanyikazi$Role == "Junior",] head(df1, 3) ``` ``` ## Sid Gender Age Department Role Income Marital_Status County ## 2 17041 Male 48 Research Analyst Junior 3387 Divorced Wajir ## 3 16232 Male 35 Operations Junior 3170 Married Mombasa ## 5 13463 Female 43 Associate Junior 1651 Married Nairobi ## Leave_Days Promotion ## 2 8 Yes ## 3 0 No ## 5 2 Yes ``` --- Select females who come from Nyeri county ```r df2 <- wafanyikazi[wafanyikazi$Gender == "Female" & wafanyikazi$County == "Nyeri",] head(df2, 3) ``` ``` ## Sid Gender Age Department Role Income Marital_Status County Leave_Days ## 4 19576 Female 41 Finance Senior 5557 Married Nyeri 8 ## 34 18997 Female 32 Associate Senior 5340 Single Nyeri 14 ## 67 19891 Female 48 Operations Senior 9029 Married Nyeri 14 ## Promotion ## 4 No ## 34 No ## 67 No ``` **De Morgan’s laws:** - `!(X & Y)` is the same as `!X | !Y` - `!(X | Y)` is the same as `!X & !Y` --- ##4.5.8 Boolean algebra versus sets (logical and integer ) Two types of subsetting. - integer subsetting: (set operations) - Effective when you want to find the first (or last) TRUE and - You have very few TRUEs and very many FALSEs; a set representation may be faster and require less storage. - logical subsetting: (Boolean algebra) `which()` allows you to convert a Boolean representation to an integer representation. ```r which(df$names %in% "John") ``` ``` ## [1] 1 ``` --- You can create a function that does the reverse i.e. converts an integer representation to a Boolean representation. Do we really need to do this? ```r unwhich <- function(x, n) { out <- rep_len(FALSE, n) out[x] <- TRUE out } unwhich(which(df$names %in% "John"), length(df$names)) ``` ``` ## [1] TRUE FALSE FALSE FALSE FALSE ``` When we can just do this? ```r df$names %in% "John" ``` ``` ## [1] TRUE FALSE FALSE FALSE FALSE ``` --- ## Relationship between Boolean and set operations. Create two logical vectors (x1 , y1) and their integer equivalents (x2, y2) ```r (x1 <- 1:10 %% 2 == 0) ``` ``` ## [1] FALSE TRUE FALSE TRUE FALSE TRUE FALSE TRUE FALSE TRUE ``` ```r (x2 <- which(x1)) ``` ``` ## [1] 2 4 6 8 10 ``` ```r (y1 <- 1:10 %% 5 == 0) ``` ``` ## [1] FALSE FALSE FALSE FALSE TRUE FALSE FALSE FALSE FALSE TRUE ``` ```r (y2 <- which(y1)) ``` ``` ## [1] 5 10 ``` --- ### X & Y <-> intersect(x, y) ```r x1 & y1 ``` ``` ## [1] FALSE FALSE FALSE FALSE FALSE FALSE FALSE FALSE FALSE TRUE ``` ```r intersect(x2, y2) ``` ``` ## [1] 10 ``` -- ### X | Y <-> union(x, y) ```r x1 | y1 ``` ``` ## [1] FALSE TRUE FALSE TRUE TRUE TRUE FALSE TRUE FALSE TRUE ``` ```r union(x2, y2) ``` ``` ## [1] 2 4 6 8 10 5 ``` --- ### X & !Y <-> setdiff(x, y) ```r x1 & !y1 ``` ``` ## [1] FALSE TRUE FALSE TRUE FALSE TRUE FALSE TRUE FALSE FALSE ``` ```r setdiff(x2, y2) ``` ``` ## [1] 2 4 6 8 ``` -- ### xor(X, Y) <-> setdiff(union(x, y), intersect(x, y)) ```r xor(x1, y1) ``` ``` ## [1] FALSE TRUE FALSE TRUE TRUE TRUE FALSE TRUE FALSE FALSE ``` ```r setdiff(union(x2, y2), intersect(x2, y2)) ``` ``` ## [1] 2 4 6 8 5 ``` --- # Exercises * How would you randomly permute the columns of a data frame? (This is an important technique in random forests.) Can you simultaneously permute the rows and columns in one step? -- ```r # Read in the data df <- rChambua::wafanyikazi head(df1, n=3) ``` ``` ## Sid Gender Age Department Role Income Marital_Status County ## 2 17041 Male 48 Research Analyst Junior 3387 Divorced Wajir ## 3 16232 Male 35 Operations Junior 3170 Married Mombasa ## 5 13463 Female 43 Associate Junior 1651 Married Nairobi ## Leave_Days Promotion ## 2 8 Yes ## 3 0 No ## 5 2 Yes ``` --- ```r # Permutate columns df1 <- df[,sample(names(df))] head(df1, n=3) ``` ``` ## Role Marital_Status Leave_Days Gender Sid Promotion Department ## 1 Mid Single 11 Male 10715 No Finance ## 2 Junior Divorced 8 Male 17041 Yes Research Analyst ## 3 Junior Married 0 Male 16232 No Operations ## County Age Income ## 1 Kisumu 31 5991 ## 2 Wajir 48 3387 ## 3 Mombasa 35 3170 ``` -- ```r # Permutate rows and columns df2 <- df[sample(nrow(df)),sample(names(df))] head(df2, n=3) ``` ``` ## Leave_Days Role Marital_Status Age Income Sid Promotion Gender County ## 224 20 Junior Married 33 7727 17704 Yes Male Nairobi ## 405 18 Senior Divorced 30 6425 17770 No Male Lamu ## 463 11 Junior Divorced 29 3604 15549 Yes Female Taita ## Department ## 224 Finance ## 405 Data ## 463 Associate ``` --- * How would you select a random sample of m rows from a data frame? What if the sample had to be contiguous (i.e., with an initial row, a final row, and every row in between)? -- ```r # Generate a vector of the first and last row ids first_last_ids <- c(1,nrow(df)) first_last_ids ``` ``` ## [1] 1 500 ``` -- ```r # Sample m (2) rows from the dataframe, excluding the first and last rows original_ids <- 1:nrow(df) other_ids <- sample(original_ids[!original_ids %in% first_last_ids] , 2) other_ids ``` ``` ## [1] 289 488 ``` -- ```r # Combine the first, last and the rows in between final_ids <- c(first_last_ids[1], other_ids, first_last_ids[2]) final_ids ``` ``` ## [1] 1 289 488 500 ``` --- ```r # Call the data, with only these specific rows df3 <- df[final_ids,] df3 ``` ``` ## Sid Gender Age Department Role Income Marital_Status County ## 1 10715 Male 31 Finance Mid 5991 Single Kisumu ## 289 14070 Male 24 Finance Junior 9680 Single Kirinyaga ## 488 19363 Female 38 Associate Junior 8378 Divorced Nyeri ## 500 16114 Female 22 Finance Junior 2736 Divorced Mombasa ## Leave_Days Promotion ## 1 11 No ## 289 2 Yes ## 488 0 No ## 500 24 Yes ``` --- * How could you put the columns in a data frame in alphabetical order? -- ```r df4 <- df[,order(names(df))] head(df4) ``` ``` ## Age County Department Gender Income Leave_Days Marital_Status ## 1 31 Kisumu Finance Male 5991 11 Single ## 2 48 Wajir Research Analyst Male 3387 8 Divorced ## 3 35 Mombasa Operations Male 3170 0 Married ## 4 41 Nyeri Finance Female 5557 8 Married ## 5 43 Nairobi Associate Female 1651 2 Married ## 6 30 Taita Finance Female 6859 9 Single ## Promotion Role Sid ## 1 No Mid 10715 ## 2 Yes Junior 17041 ## 3 No Junior 16232 ## 4 No Senior 19576 ## 5 Yes Junior 13463 ## 6 Yes Junior 19788 ``` --- # Discussion <div class="figure" style="text-align: center"> <img src="img/subset-removebg-preview.png" alt="..." width="70%" /> <p class="caption">...</p> </div>
