class: center, middle, inverse, title-slide # Advanced R by Hadley Wickham ## Chapter 4: Subsetting ### Scott Nestler ###
@ScottNestler
### 2020-04-23 --- <style> img { display: block; margin: 0 auto; } hide { display: none; } .remark-slide-content h1 { font-size: 45px; } h1 { font-size: 2em; margin-block-start: 0.67em; margin-block-end: 0.67em; } .remark-slide-content { font-size: 16px } .remark-code { font-size: 16px; } code.r { font-size: 16px; } pre { margin-top: 0px; margin-bottom: 0px; } </style> # What's in Chapter 4 - Section 4.1: Introduction & Key Points - Section 4.2: Selecting multiple elements - Section 4.3: Selecting a single element - Section 4.4: Subsetting and assignment - Section 4.5: Applications (Using subsetting to solve problems) --- # Introduction & Key Points + There are 6 ways to subset atomic vectors (more in 4.2 & 4.3) + There are 3 subsetting operators: [[, [, and $ + Subsetting operators interact differently with various vector types (e.g. atomic vectors, lists, factors, matrices, and data frames) + Subsetting and assignment can be combined ("subsassignment") + Subsetting complements structure, or `str()`, which shows you *all* the pieces of an object, but subsetting lets you pull out only the pieces you are interested in + Often useful to use RStudio Viewer, with `View(my_object)` to know which pieces you want to subset --- # Selecting Multiple Elements + Use `[` to select any number of elements from a vector (of any type), in one of 6 ways + We will use the following vector (from the beer dataset) in the examples ```r library(dplyr) brewer_size <- readr::read_csv('https://raw.githubusercontent.com/rfordatascience/tidytuesday/master/data/2020/2020-03-31/brewer_size.csv') brewers <- brewer_size %>% group_by(year) %>% summarize(sum = sum(n_of_brewers), barrels = sum(total_barrels)) %>% select(sum, barrels) %>% c() n_brewers <- brewers$sum n_barrels <- brewers$barrels n_brewers ``` ``` ## [1] 3556 3628 4186 4860 5692 6746 9008 10192 11296 11928 12800 ``` ```r n_barrels ``` ``` ## [1] 393938550 390422806 385493644 392294405 383994749 384030276 382226036 ## [8] 379679827 371163674 365581921 NA ``` --- # Selecting Multiple Elements: Approaches 1 & 2 + **Positive integers** return elements at the specified position(s). ```r n_brewers[2] # Can also be used for a single element ``` ``` ## [1] 3628 ``` ```r n_brewers[c(1,11,12)] # Note what happens with out of bounds index ``` ``` ## [1] 3556 12800 NA ``` ```r n_brewers[4:6] ``` ``` ## [1] 4860 5692 6746 ``` + **Negative integers** *exclude* elements at the specified position(s). ```r n_brewers[-11] # Omits the last (11th) value ``` ``` ## [1] 3556 3628 4186 4860 5692 6746 9008 10192 11296 11928 ``` ```r n_brewers[c(-1:-5)] # Omits the first 5 values ``` ``` ## [1] 6746 9008 10192 11296 11928 12800 ``` NOTE: You can't mix positive and negative integers in a subset --- # Selecting Multiple Elements: Approaches 3 & 4 + **Logical vectors** select elements where the corresponding logical value is true. Perhaps the most useful type of subsetting. ```r n_brewers[c(TRUE, FALSE, TRUE, FALSE, TRUE, FALSE, TRUE, FALSE, TRUE, FALSE, TRUE)] ``` ``` ## [1] 3556 4186 5692 9008 11296 12800 ``` ```r n_brewers[n_brewers > 10000] ``` ``` ## [1] 10192 11296 11928 12800 ``` ```r n_brewers[n_brewers > 4000 & n_brewers < 9000] ``` ``` ## [1] 4186 4860 5692 6746 ``` ```r n_brewers[c(TRUE, TRUE, FALSE)] # Usual recycling rules apply ``` ``` ## [1] 3556 3628 4860 5692 9008 10192 11928 12800 ``` + **Nothing** returns the original vector. Useful for matricies, data frames, and arrays (later). ```r n_brewers[] ``` ``` ## [1] 3556 3628 4186 4860 5692 6746 9008 10192 11296 11928 12800 ``` + More useful with matrices, data frames, and arrays. --- # Selecting Multiple Elements: Approaches 5 & 6 + **Zero** return returns a zero length vector. Useful for generating test data. ```r n_brewers[0] ``` ``` ## numeric(0) ``` + Helpful for generating test data + **Character vectors** return elements of vectors *with names*. ```r nb <- setNames(n_brewers, letters[1:11]) nb[c("a", "b", "c")] ``` ``` ## a b c ## 3556 3628 4186 ``` ```r nb[c("b", "b")] # Can repeat indices ``` ``` ## b b ## 3628 3628 ``` + Recommendation is to not subset with factors --- # Selecting Multiple Elements of Lists, Matrices, and Arrays + For Lists, it's the same as for an atopmic vector + `[` always returns a list; `[[` and `$` let you pull out elements (later) + For **matrices** and **arrays**, there are 3 ways: + With multiple vectors + With a single vector + With a matrix ```r A <- matrix(n_brewers[1:10], nrow = 2) A ``` ``` ## [,1] [,2] [,3] [,4] [,5] ## [1,] 3556 4186 5692 9008 11296 ## [2,] 3628 4860 6746 10192 11928 ``` ```r A[1,] # To select first row ``` ``` ## [1] 3556 4186 5692 9008 11296 ``` ```r A[,2:3] # To select 2nd and 3rd columns ``` ``` ## [,1] [,2] ## [1,] 4186 5692 ## [2,] 4860 6746 ``` ```r A[2,4] # Can also select a single element ``` ``` ## [1] 10192 ``` --- # Selecting Multiple Elements of Data Frames + Data frames have characteristics of both lists and matrices, so: + When subsetting with a single index, they behave like lists. + When subsetting with two indices, they behave like matrices. ```r B <- data.frame(year = 2009:2013, num = n_brewers[1:5], prod = n_barrels[1:5]) B[1:2] # Selects first two columns ``` ``` ## year num ## 1 2009 3556 ## 2 2010 3628 ## 3 2011 4186 ## 4 2012 4860 ## 5 2013 5692 ``` ```r B[2,] # Selects the second row ``` ``` ## year num prod ## 2 2010 3628 390422806 ``` ```r B[4,2] # Select a single element ``` ``` ## [1] 4860 ``` ```r str(B["year"]) # list subsetting does not simplify ``` ``` ## 'data.frame': 5 obs. of 1 variable: ## $ year: int 2009 2010 2011 2012 2013 ``` ```r str(B[, "year"]) # matrix subsetting simplifies by default ``` ``` ## int [1:5] 2009 2010 2011 2012 2013 ``` --- # Selecting Multiple Elements of Tibbles + Subsetting a tibble with `[` always returns a tibble. ```r C <- tibble::tibble(B) C[2,] # Selects the second row C[4,2] # Select a single element str(C["year"]) # Same as next str(C[,"year"]) # Same as previous ``` ``` ## # A tibble: 1 x 3 ## year num prod ## <int> <dbl> <dbl> ## 1 2010 3628 390422806. ## # A tibble: 1 x 1 ## num ## <dbl> ## 1 4860 ## tibble [5 x 1] (S3: tbl_df/tbl/data.frame) ## $ year: int [1:5] 2009 2010 2011 2012 2013 ## tibble [5 x 1] (S3: tbl_df/tbl/data.frame) ## $ year: int [1:5] 2009 2010 2011 2012 2013 ``` --- # Preserving Dimensionality + Subsetting a matrix or data frame with a single number will (by default) simplify the returned output to an object with lower dimensionality + You can change this with `drop = FALSE`. + Tibbles default to `drop = FALSE` because the default `drop = TRUE` behavior is a common source of bugs in functions. + Factor subsetting is different; it affects levels (not dimensions) and defaults to `FALSE`. + If you are using `drop = TRUE` a lot, you shoudl probably use a character vector instead of a factor. ```r str(A[1,]) ``` ``` ## num [1:5] 3556 4186 5692 9008 11296 ``` ```r str(A[1, , drop = FALSE]) ``` ``` ## num [1, 1:5] 3556 4186 5692 9008 11296 ``` --- # Selecting a single element + Two subsetting operators + `[[` is used for extracing single elements + `$` is just shorthand operator, i.e. x$y is the same as x[["y"]] (in 5 fewer keystrokes) + Primary use case for `[[` is when working with lists, as you get a list back. + The "train of cars" example is useful in illustrating the difference between `[` and `[[`. ```r x <- list(1:3, "a", 4:6) ``` <img src="train.png" width="60%" /> <img src="train-single.png" width="60%" /> --- # More on `[[` + `[[` can only return a single item, so you can only use it with a single positive integer or a single string. + If you use a vector with `[[`, it will subset recursively. + This means that `x[[c(1,2)]]` is equivalent to `x[[1]][[2]]` + You have to use `[[` when workign with lists, but it is recommended for extracting a single value from atomic vectors too. + For somethign like this, it probably doesn't matter. ```r n_brewers[7] ``` ``` ## [1] 9008 ``` ```r n_brewers[[7]] ``` ``` ## [1] 9008 ``` + But in code like this, somehow it does? ```r for (i in 2:length(x)) { out[i] <- fun(x[i], out[i-1]) } for (i in 2:length(x)) { out[[i]] <- fun(x[[i]], out[[i-1]]) } ``` --- # Now about `$` + As mentioned, it is a shortcut, with `x$y` being *roughly equivalent* to x[["y"]]. + Often used to access variables in data frames. + A common mistake is using it when the name of a column is stored in a variable. + An important difference betweeen `$` and `[[` is that `$` does partial (left to right) matching. + A common mistake with `$` is using it when you have the name of a column stored in a variable ```r # Tried to put an example here with the beer data set but ran out of time # and refused to use the mtcars example from the book. Will add in later. ``` --- # Missing and Out-of-Bounds Indices + What happens when you use an "invalid" index with `[[`? + Inconsistencies in this table led to the development of `purr::pluck()` and `purr::chuck`(). <table> <caption>Table from 4.3.3</caption> <thead> <tr> <th style="text-align:left;"> row[[col]] </th> <th style="text-align:left;"> Zero-length </th> <th style="text-align:left;"> OOB(int) </th> <th style="text-align:left;"> OOB(chr) </th> <th style="text-align:left;"> Missing </th> </tr> </thead> <tbody> <tr> <td style="text-align:left;"> Atomic </td> <td style="text-align:left;"> Error </td> <td style="text-align:left;"> Error </td> <td style="text-align:left;"> NULL </td> <td style="text-align:left;"> NULL </td> </tr> <tr> <td style="text-align:left;"> Error </td> <td style="text-align:left;"> Error </td> <td style="text-align:left;"> Error </td> <td style="text-align:left;"> NULL </td> <td style="text-align:left;"> NULL </td> </tr> <tr> <td style="text-align:left;"> Error </td> <td style="text-align:left;"> List </td> <td style="text-align:left;"> NULL </td> <td style="text-align:left;"> NULL </td> <td style="text-align:left;"> NULL </td> </tr> </tbody> </table> --- # @ and `slot()` Operators + These operators are needed for S4 objects (covered in Chap. 15) + @ is the equivalent of $; @ is more restrictive + `slot()` is the equivalent to `[[` --- # Subsetting and Assignment ("Subassignment") +All subsetting operators can be combined with assignment to modify selected values of the input vector. ```r n_brewers ``` ``` ## [1] 3556 3628 4186 4860 5692 6746 9008 10192 11296 11928 12800 ``` ```r n_brewers[5] <- 42 n_brewers[c(1,2)] <- c(1.618, 186282) n_brewers ``` ``` ## [1] 1.618 186282.000 4186.000 4860.000 42.000 6746.000 ## [7] 9008.000 10192.000 11296.000 11928.000 12800.000 ``` + Be sure that the length(value) is the same length of x[i] due to complex recycling rules. --- # Application - Lookup Tables ###Character Subsetting + Character matching can be used to create lookup tables. + You can use `unname()` to remove the names if you want ```r brewing_materials <- readr::read_csv('https://raw.githubusercontent.com/rfordatascience/tidytuesday/master/data/2020/2020-03-31/brewing_materials.csv') types <- substring(brewing_materials$type[1:15],1,1) types ``` ``` ## [1] "M" "C" "R" "B" "W" "T" "S" "H" "H" "O" "T" "T" "M" "C" "R" ``` ```r lookup <- c(M = "Malt", C = "Corn", R = "Rice", B = "Barley", W = "Wheat", T = "Total", S= "Sugar", H = "Hops", O = "Other") lookup[types] ``` ``` ## M C R B W T S H ## "Malt" "Corn" "Rice" "Barley" "Wheat" "Total" "Sugar" "Hops" ## H O T T M C R ## "Hops" "Other" "Total" "Total" "Malt" "Corn" "Rice" ``` ```r unname(lookup[types]) ``` ``` ## [1] "Malt" "Corn" "Rice" "Barley" "Wheat" "Total" "Sugar" "Hops" ## [9] "Hops" "Other" "Total" "Total" "Malt" "Corn" "Rice" ``` --- # Application - Matching and Merging By Hand ### Integer Subsetting + Can have more complicated lookup tables with multiple columns. + You can use `unname()` to remove the names if you want ```r grades <- c(1, 2, 2, 3, 1) info <- data.frame( grade = 3:1, desc = c("Excellent", "Good", "Poor"), fail = c(F, F, T) ) id <- match(grades, info$grade) id ``` ``` ## [1] 3 2 2 1 3 ``` ```r info[id, ] ``` ``` ## grade desc fail ## 3 1 Poor TRUE ## 2 2 Good FALSE ## 2.1 2 Good FALSE ## 1 3 Excellent FALSE ## 3.1 1 Poor TRUE ``` --- # Application - Random Samples and Bootstraps ### IntegerSubsetting + Can use integer indices to randomly sample or bootstrap a vector or data frame using `sample()`. ```r B <- data.frame(year = 2009:2013, num = n_brewers[1:5], prod = n_barrels[1:5]) B ``` ``` ## year num prod ## 1 2009 1.618 393938550 ## 2 2010 186282.000 390422806 ## 3 2011 4186.000 385493644 ## 4 2012 4860.000 392294405 ## 5 2013 42.000 383994749 ``` ```r # Randomly reorder B[sample(nrow(B)), ] ``` ``` ## year num prod ## 3 2011 4186.000 385493644 ## 2 2010 186282.000 390422806 ## 5 2013 42.000 383994749 ## 1 2009 1.618 393938550 ## 4 2012 4860.000 392294405 ``` --- # Application - Random Samples and Bootstraps (cont.) ### Integer Subsetting + Can use integer indices to randomly sampel or bootstrap a vector or data frame using `sample()`. ```r # Select 3 randow rows B[sample(nrow(B), 2), ] ``` ``` ## year num prod ## 2 2010 186282.000 390422806 ## 1 2009 1.618 393938550 ``` ```r #Select 10 bootstrap replicates B[sample(nrow(B), 10, replace = TRUE), ] ``` ``` ## year num prod ## 3 2011 4186 385493644 ## 2 2010 186282 390422806 ## 5 2013 42 383994749 ## 5.1 2013 42 383994749 ## 4 2012 4860 392294405 ## 5.2 2013 42 383994749 ## 2.1 2010 186282 390422806 ## 5.3 2013 42 383994749 ## 3.1 2011 4186 385493644 ## 4.1 2012 4860 392294405 ``` ```r # The number after decimal indicates additional occurrences ``` --- # Application - Ordering ### Integer Subsetting + Provide a vector to `order()` and it returns an integer vector describing how to order the subsetted vector. + To break ties, you can supply additional variables to `order()`. ```r types ``` ``` ## [1] "M" "C" "R" "B" "W" "T" "S" "H" "H" "O" "T" "T" "M" "C" "R" ``` ```r order(types) ``` ``` ## [1] 4 2 14 8 9 1 13 10 3 15 7 6 11 12 5 ``` ```r types[order(types)] ``` ``` ## [1] "B" "C" "C" "H" "H" "M" "M" "O" "R" "R" "S" "T" "T" "T" "W" ``` ```r types[order(types, decreasing = TRUE)] # Change order from ascending to descending ``` ``` ## [1] "W" "T" "T" "T" "S" "R" "R" "O" "M" "M" "H" "H" "C" "C" "B" ``` --- # Application - Ordering (cont.) ### Integer Subsetting + For two or more dimensions, `order()` makes it easy to order *either* the rows or columns of an object. ```r # Reorder by 'num' column B[order(B$num), ] ``` ``` ## year num prod ## 1 2009 1.618 393938550 ## 5 2013 42.000 383994749 ## 3 2011 4186.000 385493644 ## 4 2012 4860.000 392294405 ## 2 2010 186282.000 390422806 ``` ```r # Reorder by names of columns B[, order(names(B))] ``` ``` ## num prod year ## 1 1.618 393938550 2009 ## 2 186282.000 390422806 2010 ## 3 4186.000 385493644 2011 ## 4 4860.000 392294405 2012 ## 5 42.000 383994749 2013 ``` --- # Application - Expanding Aggregated Counts ### Character Subsetting + Given a data frame where identical rows have been collapsed into one and a count column, use `rep()` and integer subsetting to uncollapse. + This works because `rep(x, y)` repeats `x[i] y[i]` times. ```r df <- data.frame(x = c(2, 4, 1), y = c(9, 11, 6), n = c(3,5,1)) rep(1:nrow(df), df$n) ``` ``` ## [1] 1 1 1 2 2 2 2 2 3 ``` ```r df[rep(1:nrow(df), df$n), ] ``` ``` ## x y n ## 1 2 9 3 ## 1.1 2 9 3 ## 1.2 2 9 3 ## 2 4 11 5 ## 2.1 4 11 5 ## 2.2 4 11 5 ## 2.3 4 11 5 ## 2.4 4 11 5 ## 3 1 6 1 ``` --- # Application - Removing Columns From Data Frames ### Character Subsetting + There are two ways to remove columns from a data frame. + You can set individual columns to `NULL`. + Or you can subset to return only the columns you want. + If you only know the columns you **don't** want, use set operations to work out which columns to keep: ```r df <- data.frame(x = 1:3, y = 3:1, z = letters[1:3]) df$z <- NULL df <- data.frame(x = 1:3, y = 3:1, z = letters[1:3]) df[c("x", "y")] ``` ``` ## x y ## 1 1 3 ## 2 2 2 ## 3 3 1 ``` ```r df[setdiff(names(df), "z")] ``` ``` ## x y ## 1 1 3 ## 2 2 2 ## 3 3 1 ``` --- # Application - Selecting Rows Based on a Condition ### Logical Subsetting + To combine conditions from multiple columns use logical subsetting ```r B <- data.frame(year = 2009:2013, num = n_brewers[1:5], prod = n_barrels[1:5]) B[B$num >= 4000,] ``` ``` ## year num prod ## 2 2010 186282 390422806 ## 3 2011 4186 385493644 ## 4 2012 4860 392294405 ``` ```r B[B$num >= 4000 & B$year < 2013,] ``` ``` ## year num prod ## 2 2010 186282 390422806 ## 3 2011 4186 385493644 ## 4 2012 4860 392294405 ``` --- # Application - Boolean Algebra vs Sets ### Logical & Integer Subsetting + Using set operations is useful when: + You want to find the first (or last) `TRUE`. + You have very few `TRUE`s and very few `FALSE`s, so a set representation is faster and uses less storage + Use `which()` to convert a Boolean representation to an integer representation. + There is no reverse operation in base R, but it can be written like this: ```r x <- sample(10) < 4 which(x) ``` ``` ## [1] 1 2 4 ``` ```r unwhich <- function(x, n) { out <- rep_len(FALSE, n) out[x] <- TRUE out } unwhich(which(x), 10) ``` ``` ## [1] TRUE TRUE FALSE TRUE FALSE FALSE FALSE FALSE FALSE FALSE ``` --- # Application - Boolean Algebra vs Sets (cont.) ### Logical & Integer Subsetting + Here are two logical vectors and some operations useful in subsetting. ```r x1 <- 1:10 %% 2 == 0 # uses the mod operator `%%` to identify even numbers x2 <- which(x1) y1 <- 1:10 %% 5 == 0 # Finds numbers divisible by 5 with remainder 0 y2 <- which(y1) x1 & y1 # gives the intersection ``` ``` ## [1] FALSE FALSE FALSE FALSE FALSE FALSE FALSE FALSE FALSE TRUE ``` ```r intersect (x2, y2) # check it this way; gives even numbers ``` ``` ## [1] 10 ``` ```r x1 | y1 # gives the union ``` ``` ## [1] FALSE TRUE FALSE TRUE TRUE TRUE FALSE TRUE FALSE TRUE ``` ```r union(x2, y2) # provides even numbers and those divisible by 5 ``` ``` ## [1] 2 4 6 8 10 5 ``` ```r x1 & !y1 # gives even numbers *not* divisible by 5 ``` ``` ## [1] FALSE TRUE FALSE TRUE FALSE TRUE FALSE TRUE FALSE FALSE ``` ```r setdiff(x2, y2) # check it this way ``` ``` ## [1] 2 4 6 8 ``` --- # Application - Boolean Algebra vs Sets (cont. cont.) ### Logical & Integer Subsetting + Common mistake is using `x[which(y)]` instead of `x[y]`. Problem is that the `which()` switches from logical to integer subsetting but doesnt' really do anything here. But it can make a difference: + When there is an `NA` in the logical vector, logical subsetting replaces them with `NA`, but `which()` drops these values. + `x[-which(y)]` is **not** equivalent to `x[!y]` + Bottom line: avoid switching from logical to integer subsetting unless you really want to, like to find the first (last) `TRUE` value.
